China All Aluminum Alloy Conductor 50 95 120mm2 AAAC Cable

Product Description

AAAC Conductor (All Aluminium Alloy Conductor) 20years manufacture experience,we can produce as per the standard:IEC, BS,ASTM,DIN,NF,JIS.We can also customize the special size according to the customer's special request.

Hot sale to Africa,Southeast Asia,North America
AAAC-- ASTM B399 standard

Area		No./wire diameter	Overall diameter	Weight	Nominal breaking load	Max D.C. resistance at 20ºC	Standard length
Nominal	Actual	No./wire diameter	Overall diameter	Weight	Nominal breaking load	Max D.C. resistance at 20ºC	Standard length
AWG or MCM	mm2	mm	mm	Kg/km	KN	Ω/km	m±5%
6	13.30	7/1.554	4.67	37	4.22	2.5199	3500
4	21.15	7/1.961	5.89	58	6.71	1.5824	3000
2	33.63	7/2.474	7.42	93	10.68	0.9942	2500
1/0	53.48	7/3.119	9.36	148	16.97	0.6256	2000
2/0	67.42	7/3.503	10.51	186	20.52	0.4959	3500
3/0	85.03	7/3.932	11.80	234	25.86	0.3939	3000
4/0	107.23	7/4.417	13.26	296	32.63	0.3119	2000
250	126.66	19/2.913	14.57	349	38.93	0.2642	2000
300	152.10	19/3.193	15.97	419	46.77	0.2199	3000
350	177.35	19/3.447	17.24	489	52.25	0.1887	3000
400	202.71	19/3.686	18.43	559	59.74	0.1650	2500
450	228.00	19/3.909	19.66	629	67.19	0.1467	2000
500	253.35	19/4.120	20.60	698	74.64	0.1321	2000
550	278.60	37/3.096	21.67	768	83.80	0.1202	2000
600	303.80	37/3.233	22.63	838	91.38	0.1102	2000
650	329.25	37/3.366	23.56	908	97.94	0.1016	2000
700	354.55	37/3.493	24.45	978	102.20	0.0944	3500
750	380.20	37/3.617	25.32	1049	109.60	0.0880	3000
800	405.15	37/3.734	26.14	1117	116.80	0.0826	3000
900	456.16	37/3.962	27.73	1258	131.50	0.0733	3000
1000	506.71	37/4.176	29.23	1399	146.10	0.0660	2500

Standard: BS EN50183

Code name	Calculated area	No of wires	Diameter		Weight	Rated strength	Max D.C. resistance at 20ºC
Code name	Calculated area	No of wires	Wire	Cond	Weight	Rated strength	Max D.C. resistance at 20ºC
	mm2		mm	mm	Kg/km	KN	Ω/km
Box	18.8	7	1.85	5.55	51.4	5.55	1.7480
Acacia	23.8	7	2.08	6.24	64.9	7.02	1.3828
Almond	30.1	7	2.34	7.02	82.2	8.88	1.0926
Cedar	35.5	7	2.54	7.62	96.8	10.46	0.9273
Deodar	42.2	7	2.77	8.31	115.2	12.44	0.7797
Fir	47.8	7	2.95	8.85	130.6	14.11	0.6875
Hazel	59.9	7	3.30	9.90	163.4	17.66	0.5494
Pine	71.6	7	3.61	10.8	195.6	21.14	0.4591
Holly	84.1	7	3.91	11.7	229.5	24.79	0.3913
Willow	89.7	7	4.04	12.1	245.0	26.47	0.3665
Oak	118.9	7	4.65	14.0	324.5	65.07	0.2767
Mulberry	150.9	19	3.18	15.9	414.3	44.52	0.2192
Ash	180.7	19	3.48	17.4	496.1	53.31	0.1830
Elm	211.0	19	3.76	18.8	579.2	62.24	0.1568
Poplar	239.4	37	2.87	20.1	659.4	70.61	0.1387
Sycamore	303.2	37	3.23	22.6	835.2	89.40	0.1095
Upas	362.1	37	3.53	24.7	997.5	106.82	0.0917
Yew	479.0	37	4.06	28.4	1319.6	141.31	0.0693
Totara	498.1	37	4.14	29.0	1372.1	145.93	0.0666
Rubus	586.9	61	3.50	31.5	1622.0	173.13	0.0567
Sorbus	659.4	61	3.71	33.4	1822.5	194.53	0.0505
Araucaria	821.1	61	4.14	37.3	2269.4	242.24	0.0406
Redwood	996.2	61	4.56	41.0	2753.2	293.88	0.0334
