Coaxial Cable UL1354
Low Voltage 30V Stranded One Core Micro Coaxial Cable PRODUCT DESCRIPTION: Rated temperature: 60ºC or 80ºC Rated voltage: 30V Reference Standard: UL Subject 758, UL1581 & CSA C22.2 NO.210.2 Tinned or bare, stranded or solid copper conductor, 40 AWG minimum Solid foamed or ......
Send Inquiry
Product Description
Low Voltage 30V Stranded One Core Micro Coaxial Cable
PRODUCT DESCRIPTION:
★ Rated temperature: 60ºC or 80ºC
Rated voltage: 30V
★ Reference Standard: UL Subject 758, UL1581 & CSA C22.2 NO.210.2
★ Tinned or bare, stranded or solid copper conductor, 40 AWG minimum
★ Solid foamed or FRPE insulation
★ Tinned or bare copper wire spiral or braid shield
★ Passes UL VW-1 & CSA FT1 vertical flame test
★ Application: For internal or external wiring of TV, radio, receiver, VTR and
tape recorder,etc.
PRODUCT DESCRIPTION:
★ Rated temperature: 60ºC or 80ºC
Rated voltage: 30V
★ Reference Standard: UL Subject 758, UL1581 & CSA C22.2 NO.210.2
★ Tinned or bare, stranded or solid copper conductor, 40 AWG minimum
★ Solid foamed or FRPE insulation
★ Tinned or bare copper wire spiral or braid shield
★ Passes UL VW-1 & CSA FT1 vertical flame test
★ Application: For internal or external wiring of TV, radio, receiver, VTR and
tape recorder,etc.
| Conductor | Insulation | Braid Shield No./No./mm | Jacket | ||||
| AWG | No./mm | Dia. mm | Nom. Thick. mm | Nom.Dia. mm | Spiral Shield No./mm | Nom. Thick. mm | Nom.Dia. mm |
| 30 | 7/0.1 | 0.3 | 0.37 | 1.05 | 34/0.1 | 0.18 | 1.6 |
| 28 | 7/0.127 | 0.38 | 0.61 | 1.6 | 16/5/0.1 | 0.46 | 3 |
| 28 | 7/0.127 | 0.38 | 0.61 | 1.6 | 42/0.12 | 0.35 | 2.55 |
| 26 | 7/0.16 | 0.48 | 0.51 | 1.5 | 16/5/0.1 | 0.3 | 2.5 |
| 21 | 19/0.18 | 0.91 | 1.02 | 2.95 | 16/8/0.12 | 0.74 | 4.9 |
