AGG High Voltage Silicone Rubber Cable
Rated Temperature: -60 C to +180 CVoltage: 5kv-30kvConductors: Tin-coated copper wireInsulator: Silicone Rubbertypeconductorinsulationnominal sectionstructurenominal thicknessnominal ODMax ODmm²No./mmmmmmmmAGG-50.27/0.201.02.62.8AGG-120.27/0.......
Send Inquiry
Product Description
Rated Temperature: -60 C to +180 C
Voltage: 5kv-30kv
Conductors: Tin-coated copper wire
Insulator: Silicone Rubber
Voltage: 5kv-30kv
Conductors: Tin-coated copper wire
Insulator: Silicone Rubber
| type | conductor | insulation | |||
| nominal section | structure | nominal thickness | nominal OD | Max OD | |
| mm² | No./mm | mm | mm | mm | |
| AGG-5 | 0.2 | 7/0.20 | 1.0 | 2.6 | 2.8 |
| AGG-12 | 0.2 | 7/0.20 | 1.3 | 3.2 | 3.4 |
| AGG-15 | 0.2 | 7/0.20 | 1.7 | 4.0 | 4.2 |
| AGG-20 | 0.2 | 12/0.15 | 1.8 | 4.2 | 4.4 |
| AGG-25 | 0.2 | 12/0.15 | 2.8 | 6.2 | 6.5 |
| AGG-30 | 0.2 | 12/0.15 | 3.2 | 7.0 | 7.3 |
