Product Description

300 300v rvvp shielded flexible cable/300 300v avvr cable/iec 52 rvv 300/300v cable

Model:

RVVP,RVVPS is a kind of soft conductor insulated wire with shielding and PVC jacket,also known as electrical anti-interference flexible connection
cable,Rated voltage 300/300V.Common cores from 2-24 cores and section area including 0.12mm,0.2mm,0.3mm,0.4mm,0.5mm,1mm,1.5mm.

Description:Single core and multi-core cables with copper or tinned copper conductor;XLPE insulated and PVC sheathed,Copper wire braid.Cables
are rates at 300/300V or 300/500V and conform to IEC 60228.5

Construction:

Conductor:Plain annealed copper or tinned copper conductor

No. of core:2-24

Cross Section:0.5-25mm

Shape: Circular Compacted or shaped Stranded Conductor (Class 5)

Insulation:PVC

Identification of cores:<=5core,colorful insulation;>5 core,Black insulation with white No. ,including Yellow-Green Wire.

Shielding:Copper wire braid

Sheath:PVC

Assembly:Two,three,four or five insulated conductors are laid up together if necessary filled with non-hygroscopic material compatible with the
insulation.The filling may be omitted provided the outer shape of the cables remains practically circular and no adhesion occurs between cores and
sheath.

Application:

A good EMC for braid screen,it is good at the high EMC and narrow space.Not for use outside closed rooms.It is same with NYSLCY cable and
H05VC4V-F cable,for installation in closed conduits and tubes in door.

Standards

International:IEC 60228

China:GB/T 3956

Other standards such as BS,DIN and ICEA upon request

Certificates

CE,RoHS,CCC,SGS,ISO-9001 and more others at request

Technical data

Test Voltage:2000V,5min

Insulation resistance:>20M • Ω *Km

Operating temp.(static):-30~70 ºC

Operating temp.(flexing): -5~70 ºC

Bending Radius:15×O.D.

Flame retardance:IEC 60 332.1

Norminal cross section size of conductor:  0.5mm2, 1mm2 1.5mm2, 2.5mm2, 4mm2, 6mm2, 10mm2, 16mm2, 25mm2

Cores available: 2 cores-24 cores.

Certifications: ISO9001/14000, RoHS, CE, CCC, IEC, BS, EN, VDE Standard
