China UTP CAT6 LAN Cable 305m Gigabit Fluke-Passed Poe Compatible Blue

Product Description

UTP CAT6 LAN Cable 305m Gigabit Fluke-Passed Poe Compatible Blue

Product Description
Category 6 cable, commonly referred to as Cat6, is a cable standard for Gigabit Ethernet and other network protocols. This cable provides performance of up to 500 MHz and is suitable for 10BASE-T, 100BASE-TX (Fast Ethernet), 1000BASE-T/1000BASE-TX (Gigabit Ethernet) .

Key Features
Cable Type: CAT6Cable Length (meter): 305 meters (1000ft)Cable Conductor Material: CopperCable Jacket Material: PVC/LSZHCable Gauge: 24 AWG or 23 AWGCable Color: BlueCable Performance: 500 MHzCable Structure: Solid/stranded

Technical Data:
Supporting 1 Gigabit EthernetFor connecting devices to a router or switch or simply an Ethernet network outletPower over Ethernet (POE) and Voice Over IP (VOIP) compliantFoil shielding can prevent electromagnetic interference and thus boost performanceCat6 500 MHz Foil Shielded FTP Snagless Patch Cable

Technical Performance (100m):
Frequency	RL	ATT(20ºC)	NEXT	PHASE DELAY	Frequency	PSNEXT	ELFEXT	PSELFEXT
(MHz)	≥dB	≤dB	≥dB	≤ns	(MHz)	≥dB	≥dB	≥dB
1	20.0	2.03	74.3	570.00	1	72.3	67.8	64.8
4.0	23.0	3.78	65.3	552.00	4	63.3	55.8	52.8
8.0	24.5	5.32	60.8	546.73	8	58.8	49.7	46.7
10.0	25.0	5.95	59.3	545.38	10	57.3	47.8	44.8
16.0	25.0	7.55	56.2	543.00	16	54.2	43.7	40.7
20.0	25.0	8.47	54.8	542.05	20	52.8	41.8	38.8
25.0	24.3	9.51	53.3	541.20	25	41.3	39.8	36.8
31.25	23.6	10.67	51.9	540.44	31.25	49.9	37.9	34.9
62.5	21.5	15.38	47.7	538.55	62.5	45.4	31.9	28.9
100	20.1	19.80	44.3	537.60	100	42.3	27.8	24.8
200	18.0	28.98	39.8	536.54	200	37.8	21.8	18.8
250	17.3	32.85	38.3	536.27	250	36.3	19.8	16.8
