              Rg7 Good Cable for Communication Purpose
              • Rg7 Good Cable for Communication PurposeRg7 Good Cable for Communication Purpose
              • Rg7 Good Cable for Communication PurposeRg7 Good Cable for Communication Purpose
              • Rg7 Good Cable for Communication PurposeRg7 Good Cable for Communication Purpose

              Rg7 Good Cable for Communication Purpose

              SpecificationsConductorMaterialBC/CCSNom.Dia.1.63mmDielectricMaterialFoam PENom.Dia.7.11mmShieldMaterial26mmAl bonded foil+Al braidingCoverage40%-95%JacketMaterialPVC/PENom.Thick.1.07mmNom.Dia.10.03mmNominal Impedance(ohm)75±3Nominal Velocity of Propagation(%)85Nominal Capacitance(pF/m)50......

              Send Inquiry

              Product Description

              Specifications

              Conductor

              Material

              BC/CCS

              Nom.Dia.

              1.63mm

              Dielectric

              Material

              Foam PE

              Nom.Dia.

              7.11mm

              Shield

              Material

              26mmAl bonded foil+Al braiding

              Coverage

              40%-95%

              Jacket

              Material

              PVC/PE

              Nom.Thick.

              1.07mm

              Nom.Dia.

              10.03mm

              Nominal Impedance(ohm)

              75±3

              Nominal Velocity of Propagation(%)

              85

              Nominal Capacitance(pF/m)

              50

              Sparker Test(VAC)

              4000

              SRL(dB)

              20

              20

              Attenuation(68°F(20°C))

               Frequency(MHz)

               Maximum(dB/100ft)

               Maximum(dB/100m)



               5

               0.38

               1.25



               55

               0.96

               3.15



               187

               2.05

               6.72



               300

               2.25

               7.38



               450

               2.75

              9.02



               600

               3.18

              10.43



               750

               3.65

              11.97



               865

               3.98

              13.05



               1000

               4.35

              14.27







              Quick Details

              • Place of Origin:

              • Zhejiang, China (Mainland)

              • Brand Name:

              • HF/OEM/ODM

              • Model Number:

              • RG11

              • Number of Conductors:

              • 1

              • HS Code:

              • 8544200000

              • Color:

              • Any color

              • Conductor Material:

              • 1.63mm BC/CCS

              • Dielectric:

              • 7.11mm Foam PE

              • Shield:

              • 30%-95% BC/Al Braiding

              • Jacket:

              • 10.03mm PVC/PE

              • Application:

              • CATV/Satellite

              • Certification:

              • ETL/CE/ROHS/UL/ISO9001



              1.02 Bare COPPER(BC) +4.57 FPE+ Bonded Al foil+64*0.16Al-Mg coverage 60%+6.91 PVC

              1) Construction

              Center Conductor:

              1.02+0.01mm PURE COPPER(BC)

              Dielectric:

              4.57+0.1mmFoam PE

              Shield:

              Al Foil/Bonded Al Foil

              Braid Coverage:

              64*0.16AL ,60%

              Jacket:

              6.91+0.1mm PVC

              Jelly/APD

              Per Customers' Special Requirement

              2) Characteristics

              Sparker Test:4000VACImpedance:75+3 OhmCapacitance:54+3pF/mVelocity of Propagation:85%Return Loss:20dB min (5-2300MHz)
